Print-in-place Articulated Starwars ATAT


You can download 1 free item per Free item - download ticket.

Sign up and Download it
Free item - download ticket?


GOODesign is a design studio established in Seoul, Korea by a representative who has been active in product design and 3D CG field for 20 years. As a design company that pursues a reasonable and differentiated digital design, it has always presented a new direction through working with clients such as Hyundai Motor, Siemens Korea and beiersdorf. This time, we have put out the life product for 3D printing by utilizing various technique design based on the shape of the Class-A surface. These products are especially the result of deep research on the 3D printing dominant shape that can not be mass-produced using a mold.

Requests from have received numerous requests from customers. Among them, there are the most requests for Star Wars items, and this time we created ATAT, which received the most requests. ATAT stands for All Terrain Armored Transport and first appeared in the Star Wars .

The characteristics of ATAT designed this time are first of all,
1) Almost every detail is described. It has described more detail than any ATAT produced by 3D printing so far.
2) Using the print-in-place and folding structure, almost all movements were implemented with just a few printings.

How to make after printing is as follows.
1. Rotate and attach the neck to the connected lower body.
※ Caution※ If the neck is not attached to the lower body first, the upper body cannot be properly connected later.
2. Put the upper body on the lower body. At this time, use the elasticity to slightly open and fit. Then, attach the side parts to the upper body with adhesive.
3. Push the head and put it on the neck.
4. Fold the ankle and attach it to the leg with adhesive.
5. Push the foot and put it on the leg.
6. Glue the 4 legs prepared in this way to the body.

Since the legs and neck can move in multiple angles, it is possible to create a scene in the movie.

If you are having problems with printing, check out our printing tips.

1 : 144 scale

Size, X 70mm, Y 191mm, Z 157mm

PRUSA Slicing Settings Simplify 3D
Extuder Nozzle Diameter : 0.4mm / Retraction Distance : 2.4~2.6mm or Retraction Distance : 1.2mm, Retraction Vertical Lift : 0.6mm
Layer Settings Layer Height : 0.1mm, 0.2mm / Top Solid : 8 / Bottom Solid : 6 / Outline : 2
First Layer Settings First Layer Height : 100% / First Layer Width : 98% / First Layer Speed : 50%
Infill Interlor Fill Percentage : 10% / Outline Overlap : 35%
Additions Raft : OK / Brim : NO / Support : NO
PRUSA Slicing Settings PrusaSlicer
PRUSA MK3 Layer Height : 0.1mm, 0.2mm / Raft : OK / Brim : NO / Support : NO
Ender Slicing Settings Simplify 3D
Extuder Nozzle Diameter : 0.4mm / Retraction Distance : 5.4mm
Layer Settings Layer Height : 0.1mm, 0.2mm / Top Solid : 8 / Bottom Solid : 6 / Outline : 2
First Layer Settings First Layer Height : 120% / First Layer Width : 95% / First Layer Speed : 50%
Infill Interlor Fill Percentage : 10% / Outline Overlap : 55%
Additions Raft : OK / Brim : NO / Support : NO
CR-10S Pro Slicing Settings Cura
Quality Layer Height : 0.1mm, 0.2mm / Line Width : 0.4mm
Shell Wall Line Count : 2 / Top Solid : 8 / Bottom Solid : 6
Infill Infill Density : 20% / Patten : Grid
Material Flow : 100% / Retraction Distance : 5.4mm
Build Plate Adhesion Raft / Raft Extra Margin : 3mm / Raft Air Gap : 0.3~0.32mm
File 22.7 MB
Release Date
Average Time
[0.1mm] ATAT Head : 3h 30m
[0.1mm] ATAT Cover : 9h
[0.1mm] ATAT Body : 10h 30m
[0.1mm] ATAT Leg : 2h x4
[0.1mm] ATAT Foot : 1h 30m x4
  • anna.dzd4314
    2023-10-11 23:04:18

    I have problems with all joints. T.T
    Foot, legs, body.
    The parts that I can save are the upper body and the head.
    So sad

  • JanBerlin
    2023-07-09 07:36:44


  • levidavidson0027639
    2023-05-24 20:57:05

    I cant get the legs to move I have try everything any advice would help thank you

  • euan.webster5894
    2023-02-24 02:59:46

    Hi, I may be being stupid, but the ZIP file only seems to have 7 parts. 4x legs, 1x main body, 1x head, foot. The neck and underbody seem to be missing from the file. Can someone advise please?

  • elowenhollow
    2023-02-12 08:55:31

    Hi, I'm printing this on a cr10 v3 the body and chassis look fantastic. Have a couple of questions 1. would putting Ironing mode on effect the moveable joints (just after the next level of smoothness)?
    2. when scaling up or down do you have any recommendations as to any changes to settings as I want one for my desk and the other in the yard possibly 1/16th scale

  • przemek.cwieluch4800
    2022-12-28 06:51:34

    what is the scale?

    2023-10-09 13:22:18

    The Description says it is 1 : 144 scale

  • simon1256
    2022-12-27 19:53:53

    Intend to print this as soon as my Anycubic Vyper finishes it's current job, but are you serious about the body cover needing NO support??

    2023-10-09 13:29:07

    I'm using a Bambu X1 Carbon and the body absolutely must have manual supports added to the neck or it detaches from the build plate EVERY time and ruins the print.

    Make sure you manually add them only to the neck, if you use auto supports it will ad them to the joints immobilizing them.

    I get a much cleaner result using auto tree supports to on the cover as well, but it does look fine on the outside without them. The inside will just be sloppy.

  • details3d7508782
    2022-09-29 00:36:07

    las patas son las mismas? por que vienen en stl distintos ?

    2023-03-07 15:45:52

    cada pata corresponde a un lado especifico

  • lambflirta7972
    2022-06-03 08:02:26

    Patrolling the bottom of my tank

  • cadoret405119
    2022-03-29 01:20:43

    100% scale
    Eryone light grey filament

    Was not able to activate the knee joint, it's fuse together. (my printer is not setup completely yet)

    Great model tks.
