F-22 Raptor

$ 6.99

Designer

GOODesign

GOODesign is a design studio established in Seoul, Korea by a representative who has been active in product design and 3D CG field for 20 years. As a design company that pursues a reasonable and differentiated digital design, it has always presented a new direction through working with clients such as Hyundai Motor, Siemens Korea and beiersdorf. This time, we have put out the life product for 3D printing by utilizing various technique design based on the shape of the Class-A surface. These products are especially the result of deep research on the 3D printing dominant shape that can not be mass-produced using a mold.

In response to numerous requests from customers, I designed the F-22 Raptor for 3D printing.
The main features are:
1. The missile hangar can be opened and closed.
2. The angle of the wing flaps can be changed.
3. The angle of the horizontal tail wings can be changed.
4. The angle of the thrust vectoring flap at the rear of the engine can be changed.
5. Landing gears can be equipped.

Precautions to be taken when printing and making are as follows:

1. When printing wings, it is recommended to use a brim so that it does not fall off the bed during printing.
2. If the brim is not cut accurately, the parts may not fit well, so please remove the brim carefully.
3. The flap of the main wing is not designed to move, but is designed to be attached to the user's desired angle.
4. Hold the thrust vectoring flap at the rear of the engine with pliers and turn it into place.

1 : 72 Scale
Largest part in printing, size = X 93mm, Y 130mm, Z 132mm, After full assembly size= X 194mm, Y 263mm, Z 73mm

PRUSA Slicing Settings Simplify 3D
Extuder Nozzle Diameter : 0.4mm / Retraction Distance : 2.4mm
Layer Settings Layer Height : 0.1mm, 0.2mm / Top Solid : 8 / Bottom Solid : 6 / Outline : 2
First Layer Settings First Layer Height : 100% / First Layer Width : 100% / First Layer Speed : 80%
Infill Interlor Fill Percentage : 15% / Outline Overlap : 30%
Additions Raft : OK / Brim : NO / Support : NO
PRUSA Slicing Settings PrusaSlicer
PRUSA MK3 Layer Height : 0.1mm, 0.2mm / Raft : OK / Brim : NO / Support : NO
Ender Slicing Settings Simplify 3D
Extuder Nozzle Diameter : 0.4mm / Retraction Distance : 5.4mm
Layer Settings Layer Height : 0.1mm, 0.2mm / Top Solid : 8 / Bottom Solid : 6 / Outline : 2
First Layer Settings First Layer Height : 120% / First Layer Width : 150% / First Layer Speed : 50%
Infill Interlor Fill Percentage : 15% / Outline Overlap : 30~40%
Additions Raft : OK / Brim : NO / Support : NO
CR-10S Pro Slicing Settings Cura
Quality Layer Height : 0.1mm, 0.2mm / Line Width : 0.4mm
Shell Wall Line Count : 2 / Top Solid : 8 / Bottom Solid : 6
Infill Infill Density : 20% / Patten : Grid
Material Flow : 100% / Retraction Distance : 5.4mm
Build Plate Adhesion Raft / Raft Extra Margin : 3mm / Raft Air Gap : 0.3~0.32mm
File
File 23.1 MB
Release Date
2021-11-11
Average Time
[0.1mm] Canopy : 40m
[0.1mm] Fuselage : 20h
[0.1mm] Fuselage Joint : 30m
[0.1mm] Wing : 4h x2
[0.1mm] Flap : 1h
[0.1mm] Vertical tail plane : 3h 30m
[0.1mm] Horizontal tail plane : 2h
[0.1mm] Horizontal tail plane Joint : 5m
[0.1mm] Landing gear : 2h 30m(Total)
[0.1mm] Thrust vectoring flap : 1h(Total)
[0.1mm] Stand : 8h
  • ian11.soccer5054
    2023-06-06 08:48:07

    Could you share the Prusa slicer configuration you used to print? I cannot get the wings to print well, the top starts shaking when the part gets tall and fails.

    Thank you!

  • raidramon30008902
    2022-09-14 17:18:00

    Amazing design, definitely going to purhase and print.

    Any chance of designing a printable YF-23 BlackWidow ?

    Would be amazing to have them as a pair.

    fab365
    2023-05-23 16:59:42

    Hi Raidramon30008902,

    That is a great idea! If you have any requests about future models, please post them on the request section please!

    Thank You

  • dennis3191
    2022-07-08 13:25:46

    What kind of glue are you using for this model please?

    fab365
    2022-08-07 18:29:21
  • drizztguen776088
    2022-07-07 23:00:52

    When printing the main fuselage do you use supports? There are some parts I can't see how they can print without supports but if I add supports it looks like it will be very difficult to get it clean. Or do you just add manual supports in a few places?

    dennis3191
    2022-07-08 13:27:55

    I am currently printing this and the model already includes supports where needed. Just leave them turned off in your slicer. For the fuselage, there is just one section in the middle that needed supports, which is already included in the download for that section.

  • cruzseth2694
    2022-06-22 22:05:56

    can this be printed with resin?

    twelveparsex
    2023-07-10 19:46:42

    I printed it in resin. There are a few parts that are very challenging to print like the weapons bay and the joint between the forward and aft fuselage. The wings and horizontal stabs turn out very well,

  • scaryxxl7531
    2022-06-01 21:39:42

    there is not printing manual??

    fab365
    2022-06-07 14:46:19

    There is no manual. Please refer to the video.
    https://youtu.be/g8zTFA63Ng0
    https://youtu.be/RSct8a6ZDIk

  • Owais
    2022-03-24 21:45:42

    What a marvellious piece of work

    fab365
    2022-08-07 19:32:05

    Thank you very much~ Please enjoy~

  • samuellazea5318
    2022-02-07 01:51:14

    Where can I find some printing instructions please? Thanks

    fab365
    2022-06-07 14:47:46

    There is no manual. Please refer to the video.
    https://youtu.be/g8zTFA63Ng0
    https://youtu.be/RSct8a6ZDIk

  • space99
    2021-11-18 15:27:09

    can this model be scaled down?

    fab365
    2022-01-05 16:43:23

    We do not recommend scale down.
    But scale up is very good.
