Mini Cooper Union jack

$ 4.99

Designer

GOODesign

GOODesign is a design studio established in Seoul, Korea by a representative who has been active in product design and 3D CG field for 20 years. As a design company that pursues a reasonable and differentiated digital design, it has always presented a new direction through working with clients such as Hyundai Motor, Siemens Korea and beiersdorf.   This time, we have put out the life product for 3D printing by utilizing various technique design based on the shape of the Class-A surface. These products are especially the result of deep research on the 3D printing dominant shape that can not be mass-produced using a mold.

When I l previously launched my Morris Mini Cooper 3D printing design, numerous customers have been asking me to design the Union Jack version of the Mini Cooper. Some of the customers were too eager that they couldn’t wait and created their own version of the Union Jack. So, according to the customer’s wishes and requests, this is my design for the Mini Cooper Union Jack.

The assembling of this design is similar to the previous Mini Coopers I’ve designed except for the roof. There will be a protrusion on the roof with the shape of the Union Jack so that you won’t get confused when you are attaching the Union Jack to the roof. Please make sure to glue to Union Jack together when assembling.

Printing on Ender 3 3D printer video
Printing on Prusa 3D printer video

Fab365.net wants to listen to your requests as much as possible. We are always open to new designs so please do not hesitate to reach out to us for design requests.

1 : 38 Scale
Largest part in printing, size = X 92mm, Y 106mm, Z 20mm, After full assembly size= X 42mm, Y 84mm, Z 36mm
Total Build time : 16h 30m / Plastic weight : 56g

PRUSA Slicing Settings Simplify 3D
Extruder Nozzle Diameter : 0.4mm / Retraction Distance : 2.4mm
Layer Settings Layer Height : 0.1mm(High Quality) or 0.2mm(Low Quality) / Top Solid : 8 / Bottom Solid : 6 / Outline : 2
First Layer Settings First Layer Height : 100% / First Layer Width : 100% / First Layer Speed : 80%
Infill Interior Fill Percentage : 15% / Outline Overlap : 30%
Additions Raft : NO / Brim : NO / Support : NO
PRUSA Slicing Settings Prusa Slicer
PRUSA MK3 Layer Height : 0.1mm(High Quality) or 0.2mm(Low Quality) / Raft : NO / Brim : NO / Support : NO
Ender Slicing Settings Simplify 3D
Extruder Nozzle Diameter : 0.4mm / Retraction Distance : 5.4mm
Layer Settings Layer Height : 0.1mm(High Quality) or 0.2mm(Low Quality) / Top Solid : 8 / Bottom Solid : 6 / Outline : 2
First Layer Settings First Layer Height : 120% / First Layer Width : 150% / First Layer Speed : 50%
Infill Interior Fill Percentage : 15% / Outline Overlap : 30~40%
Additions Raft : NO / Brim : NO / Support : NO
Ender Slicing Settings Cura
Quality Layer Height : 0.1mm(High Quality) or 0.2mm(Low Quality) / Line Width : 0.4mm
Shell Wall Line Count : 2 / Top Solid : 8 / Bottom Solid : 6
Infill Infill Density : 20% / Pattern : Grid
Material Flow : 100% / Retraction Distance : 5.4mm
Additions Raft : NO / Brim : NO / Support : NO
CR-10S Pro Slicing Settings Cura
Quality Layer Height : 0.1mm(High Quality) or 0.2mm(Low Quality) / Line Width : 0.4mm
Shell Wall Line Count : 2 / Top Solid : 8 / Bottom Solid : 6
Infill Infill Density : 20% / Pattern : Grid
Material Flow : 100% / Retraction Distance : 5.4mm
Additions Raft : NO / Brim : NO / Support : NO
File
File 21.3 MB
Average Time
[0.1mm] Roof Union jack-White : 40m / 2g
[0.1mm] Roof Union jack-Red : 20m / 1g
[0.1mm] Roof Union jack-Blue : 20m / 1g
[0.1mm] Body : 8h / 30g
[0.1mm] Hood : 40m / 1g
[0.1mm] Hood Stripe : 10m / 1g
[0.1mm] Window : 1h / 3g
[0.1mm] Headlight : 10m / 1g
[0.1mm] Engine : 20m / 1g
[0.1mm] Radiator grille : 10m / 1g
[0.1mm] Bumper : 10m / 1g
[0.1mm] Underbody : 3h 30m / 10g
[0.1mm] Wheel cap : 20m / 1g
[0.1mm] Tire : 40m / 2g
